Description
Gimbal
| Number of Axes | 3-Axis (Pitch, Roll, Yaw) |
| Rotation Range | Yaw (Pan): 360° Pitch (Tilt): -240 to 95° Roll: -112 to 214° |
| Load Capacity | 6.6 lb / 3 kg |
Connectivity
| Ports | 3 x USB Type-C |
| Wireless Frequency | 2.4 GHz (2.4 – 2.483) |
| Wireless Protocol | Bluetooth 5.0 |
Battery
| Battery Type | 2 x 18650 |
| Capacity (mAh) | 3400 mAh |
| Capacity (Wh) | 24.48 Wh |
| Battery Runtime | 14 Hours |
Environmental
| Operating Temperature | -4 to 113°F / -20 to 45°C |
General
| Materials | Aluminum |
| Mounting | 1 x 1/4″-20 Female 1 x Cold Shoe Mount 2 x NATO Rail 4 x M4 Female |
| Dimensions | 15.7 x 7.3 x 6.9″ / 40 x 18.5 x 17.5 cm 10.2 x 8.3 x 3″ / 26 x 21 x 7.5 cm (Folded) |
| Weight | 2.681 lb / 1.216 kg (without Battery) 2.906 lb / 1.318 kg (with Camera Plate) |
Packaging Info
| Package Weight | 4.95 lb |
| Box Dimensions (LxWxH) | 12.3 x 11 x 4.2″ |
